API observations in API hub

This page applies to Apigee and Apigee hybrid.

The API observations feature in API hub helps you address the challenges of undocumented and unmanaged APIs, also known as shadow APIs, which can introduce significant security and governance risks in your API infrastructure. Evolving from the Shadow API Discovery feature in Apigee, API observations in API hub uses automated discovery processes to find and catalog all your APIs—both known and unknown—into a single, unified, and managed view.

How API observations works

API observations provides a comprehensive and continuously updated view of your API infrastructure. It works by automatically finding and cataloging undocumented or unmanaged APIs through the analysis of network traffic within your ingested data sources. This process of discovering and observing APIs is referred to as an API observation.

The process of discovering and observing an API is referred to as an observation. An API observation is the result of combining API signals to represent a detected API endpoint and its operations. It's important to note that an API observation is not a complete API definition; it can represent one or more potential APIs depending on the scope of the observed endpoint. Once detected, these discovered API observations are automatically sent to and cataloged in API hub, creating a single, searchable catalog of all your APIs.

Enable API observations in API hub

To use API observations in API hub, you must first associate your desired API assets or data sources with API hub. You can do this while attaching Apigee runtime projects to API hub. For more information, see Configure API observations in API hub.

API observations in API hub relies on the Apigee Shadow API Discovery feature, which is included as part of the paid Apigee Advanced API Security add-on. This means that in order to use API observations in API hub, you must also have the Advanced API Security add-on enabled for your Apigee organization. The Advanced API Security add-on is available for Google Cloud projects with or without Apigee provisioning:

• For subscription customers, the Advanced API Security add-on is available with the Apigee organization. See Manage Advanced API Security for Subscription organizations.
• For pay-as-you-go customers, the add-on must be enabled for at least one Apigee environment. See Manage Advanced API Security for Pay-as-you-go organizations.
• For Google Cloud projects not provisioned for Apigee, you can enable the Advanced API Security add-on by contacting Apigee Sales.
• Shadow API Discovery is not available for Apigee evaluation environments.

Supported data sources

API observations in API hub supports the following data source:

Data source	How to enable	Description
Apigee	Attach Apigee runtime projects to API hub	When you attach an Apigee runtime project to API hub, it automatically imports Apigee API observation jobs from that project. APIs discovered by these jobs are then analyzed and compared to documented APIs in API hub. If an API is a match, it is cataloged. If no match is found, the API is marked as unknown.

Discovered API observations

The API observations page in API hub displays a list of all detected APIs from all associated data sources, including both known and unknown APIs. For each discovered API observation, the following details are collected and displayed:

• Hostname: the hostname of the data source from which the API observation was collected.
• Observations: the total number of API operations, categorized as known and unknown, for the observation.
• Server IPs: a comma-separated list of all observed IP addresses.
• Source Type: the primary data source from which the observation was collected.
• Project ID: the Google Cloud project ID associated with the observation.
• Source Locations: a comma-separated list of all the geographical locations where the observation was detected.
• Observed By: the name and location of the Apigee API Observation job that initially detected the observation (this column is only available if the source is from Apigee).
• Last Event Detected (UTC): the timestamp (in UTC) of the most recent detection of the discovered API observation

IAM roles and permissions

To use API observations in API hub, you need the following IAM roles and permissions:

IAM roles	Permissions
API Management Admin (roles/apim.admin)	apim.operations.delete apim.operations.cancel apim.observationSources.create apim.observationSources.delete apim.observationJobs.create apim.observationJobs.enable apim.observationJobs.disable apim.observationJobs.delete apim.apiObservations.batchEditTags
API Management Viewer (roles/apim.viewer)	resourcemanager.projects.get resourcemanager.projects.list apim.operations.list apim.operations.get apim.locations.list apim.locations.get apim.locations.listApiObservationTags apim.observationSources.list apim.observationSources.get apim.observationJobs.list apim.observationJobs.get apim.apiObservations.list apim.apiObservations.get apim.apiOperations.list apim.apiOperations.get apim.entitlements.get
Provisioning Admin Role (roles/apihub.provisioningAdmin)	apihub.runtimeProjectAttachments.create apihub.hostProjects.attach
Viewer Role (roles/apihub.viewer)	apihub.discoveredObservations.list apihub.discoveredObservations.get apihub.discoveredOperations.list apihub.discoveredOperations.get

Pricing and billing

The API observations feature in API hub is provided at no direct cost. However, since API observations in API hub leverages Shadow API discovery, which is part of the Apigee Advanced API Security add-on, you can incur charges related to your Apigee usage. While the feature itself doesn't have direct costs, the discovery and observation process can involve data processing from your existing Apigee runtime projects, which can incur charges or hit quota limits.

For more information, see Shadow API Discovery.

What's next

• Configure API observations in API hub.
• Manage API observations.
