產品搜尋教學課程

本教學課程將示範如何建立產品集,其中包含一組產品,以及這些產品的參考圖片。本教學課程將說明如何透過線上 (個別) 匯入功能建立產品組合。產品集編入索引後,即可使用 Vision API Product Search 查詢產品集。

您在本教學課程中將學習以下內容:

  1. 透過線上 (個別) 匯入建立產品集
  2. 建立個別產品
  3. 將產品新增至產品集
  4. 更新產品
  5. 建立參考圖片
  6. 搜尋類似產品

事前準備

開始學習本教學課程前,請務必安裝適當的用戶端程式庫為專案啟用帳單和 API,並正確設定驗證

匯入程式庫

如要使用 Vision API Product Search,請下載並安裝用戶端程式庫,然後匯入下列模組:

Go

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Go API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


import (
	"context"
	"fmt"
	"io"

	vision "cloud.google.com/go/vision/apiv1"
	"cloud.google.com/go/vision/v2/apiv1/visionpb"
)

Java

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Java API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

import com.google.api.gax.longrunning.OperationFuture;
import com.google.cloud.vision.v1.BatchOperationMetadata;
import com.google.cloud.vision.v1.ImportProductSetsGcsSource;
import com.google.cloud.vision.v1.ImportProductSetsGcsSource.Builder;
import com.google.cloud.vision.v1.ImportProductSetsInputConfig;
import com.google.cloud.vision.v1.ImportProductSetsResponse;
import com.google.cloud.vision.v1.LocationName;
import com.google.cloud.vision.v1.ProductSearchClient;
import com.google.cloud.vision.v1.ReferenceImage;
import java.io.PrintStream;
import javax.swing.JPanel;
import net.sourceforge.argparse4j.ArgumentParsers;
import net.sourceforge.argparse4j.inf.ArgumentParser;
import net.sourceforge.argparse4j.inf.ArgumentParserException;
import net.sourceforge.argparse4j.inf.Namespace;
import net.sourceforge.argparse4j.inf.Subparser;
import net.sourceforge.argparse4j.inf.Subparsers;

Node.js

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Node.js API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

const vision = require('@google-cloud/vision');

Python

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Python API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

from google.cloud import vision

其他語言

C#: 請按照用戶端程式庫頁面的 C# 設定說明操作, 然後前往 .NET 適用的 Vision API Product Search 參考說明文件

PHP: 請按照用戶端程式庫頁面上的 PHP 設定說明 操作,然後前往 PHP 適用的 Vision API 產品搜尋參考文件

Ruby: 請按照用戶端程式庫頁面的 Ruby 設定說明操作, 然後前往 Ruby 適用的 Vision API Product Search 參考說明文件

執行應用程式

步驟 1:建立產品目錄

使用者有兩種方式可以建立產品目錄:透過 CSV 檔案批次匯入,或透過線上匯入。前者可透過單一 API 呼叫匯入整個產品目錄,後者則可控管產品組合,並一次管理一項資源或關係。這主要是指個別建立產品集、產品和參考圖片。你也可以透過線上匯入功能,以漸進方式更新已透過批次匯入建立的產品目錄。

在本教學課程中,您將使用線上匯入功能。如需使用 CSV 檔案進行批次匯入的範例,請參閱快速入門導覽課程

線上 (個人) 匯入

1. 建立產品集

建立空的產品集,這是產品群組的簡單容器。

要求

執行下列要求,使用 create_product_set() 方法建立空白的產品組合,並命名為「PS_CLOTH-SHOE_070318」。將產品組合 ID 和顯示名稱做為引數傳遞。

REST

使用任何要求資料之前,請先替換以下項目:

  • PROJECT_ID:您的 Google Cloud 專案 ID。
  • LOCATION_ID:有效的地點 ID。有效的位置識別碼包括:us-west1us-east1europe-west1asia-east1
  • DISPLAY_NAME:您選擇的字串顯示名稱。

HTTP 方法和網址:

POST https://vision.googleapis.com/v1/projects/project-id/locations/location-id/productSets

JSON 要求主體:

{
  "displayName": "display-name"
}

如要傳送要求,請選擇以下其中一個選項:

curl

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

curl -X POST \
-H "Authorization: Bearer $(gcloud auth print-access-token)" \
-H "x-goog-user-project: project-id" \
-H "Content-Type: application/json; charset=utf-8" \
-d @request.json \
"https://vision.googleapis.com/v1/projects/project-id/locations/location-id/productSets"

PowerShell

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred"; "x-goog-user-project" = "project-id" }

Invoke-WebRequest `
-Method POST `
-Headers $headers `
-ContentType: "application/json; charset=utf-8" `
-InFile request.json `
-Uri "https://vision.googleapis.com/v1/projects/project-id/locations/location-id/productSets" | Select-Object -Expand Content

如果要求成功,伺服器會傳回 200 OK HTTP 狀態碼與 JSON 格式的回應。

畫面會顯示類似以下的輸出。您可以使用產品集 ID (本例中為 b6d809615b6dd675),對產品集執行其他作業。

{
  "name": "projects/project-id/locations/location-id/productSets/b6d809615b6dd675",
  "displayName": "new-product-set"
}

Go

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Go API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


import (
	"context"
	"fmt"
	"io"

	vision "cloud.google.com/go/vision/apiv1"
	"cloud.google.com/go/vision/v2/apiv1/visionpb"
)

// createProductSet creates a product set.
func createProductSet(w io.Writer, projectID string, location string, productSetID string, productSetDisplayName string) error {
	ctx := context.Background()
	c, err := vision.NewProductSearchClient(ctx)
	if err != nil {
		return fmt.Errorf("NewProductSearchClient: %w", err)
	}
	defer c.Close()

	req := &visionpb.CreateProductSetRequest{
		Parent:       fmt.Sprintf("projects/%s/locations/%s", projectID, location),
		ProductSetId: productSetID,
		ProductSet: &visionpb.ProductSet{
			DisplayName: productSetDisplayName,
		},
	}

	resp, err := c.CreateProductSet(ctx, req)
	if err != nil {
		return fmt.Errorf("CreateProductSet: %w", err)
	}

	fmt.Fprintf(w, "Product set name: %s\n", resp.Name)

	return nil
}

Java

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Java API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

/**
 * Create a product set
 *
 * @param projectId - Id of the project.
 * @param computeRegion - Region name.
 * @param productSetId - Id of the product set.
 * @param productSetDisplayName - Display name of the product set.
 * @throws IOException - on I/O errors.
 */
public static void createProductSet(
    String projectId, String computeRegion, String productSetId, String productSetDisplayName)
    throws IOException {
  try (ProductSearchClient client = ProductSearchClient.create()) {

    // A resource that represents Google Cloud Platform location.
    String formattedParent = LocationName.format(projectId, computeRegion);

    // Create a product set with the product set specification in the region.
    ProductSet myProductSet =
        ProductSet.newBuilder().setDisplayName(productSetDisplayName).build();
    CreateProductSetRequest request =
        CreateProductSetRequest.newBuilder()
            .setParent(formattedParent)
            .setProductSet(myProductSet)
            .setProductSetId(productSetId)
            .build();
    ProductSet productSet = client.createProductSet(request);
    // Display the product set information
    System.out.println(String.format("Product set name: %s", productSet.getName()));
  }
}

Node.js

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Node.js API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

// Imports the Google Cloud client library
const vision = require('@google-cloud/vision');

// Creates a client
const client = new vision.ProductSearchClient();

async function createProductSet() {
  /**
   * TODO(developer): Uncomment the following line before running the sample.
   */
  // const projectId = 'Your Google Cloud project Id';
  // const location = 'A compute region name';
  // const productSetId = 'Id of the product set';
  // const productSetDisplayName = 'Display name of the product set';

  // Resource path that represents Google Cloud Platform location.
  const locationPath = client.locationPath(projectId, location);

  const productSet = {
    displayName: productSetDisplayName,
  };

  const request = {
    parent: locationPath,
    productSet: productSet,
    productSetId: productSetId,
  };

  const [createdProductSet] = await client.createProductSet(request);
  console.log(`Product Set name: ${createdProductSet.name}`);
}
createProductSet();

Python

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Python API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

from google.cloud import vision

def create_product_set(project_id, location, product_set_id, product_set_display_name):
    """Create a product set.
    Args:
        project_id: Id of the project.
        location: A compute region name.
        product_set_id: Id of the product set.
        product_set_display_name: Display name of the product set.
    """
    client = vision.ProductSearchClient()

    # A resource that represents Google Cloud Platform location.
    location_path = f"projects/{project_id}/locations/{location}"

    # Create a product set with the product set specification in the region.
    product_set = vision.ProductSet(display_name=product_set_display_name)

    # The response is the product set with `name` populated.
    response = client.create_product_set(
        parent=location_path, product_set=product_set, product_set_id=product_set_id
    )

    # Display the product set information.
    print(f"Product set name: {response.name}")


其他語言

C#: 請按照用戶端程式庫頁面的 C# 設定說明操作, 然後前往 .NET 適用的 Vision API Product Search 參考說明文件

PHP: 請按照用戶端程式庫頁面上的 PHP 設定說明 操作,然後前往 PHP 適用的 Vision API 產品搜尋參考文件

Ruby: 請按照用戶端程式庫頁面的 Ruby 設定說明操作, 然後前往 Ruby 適用的 Vision API Product Search 參考說明文件

回應

Product set name: projects/prj-prod-search-tutorials/locations/us-east1/productSets/PS_CLOTH-SHOE_070318
Product set id: PS_CLOTH-SHOE_070318
Product set display name: CLOTH-SHOE

2. 建立產品

建立產品組合後,下一步就是建立產品。 執行下列要求來建立產品。

REST

使用任何要求資料之前,請先替換以下項目:

  • PROJECT_ID:您的 Google Cloud 專案 ID。
  • LOCATION_ID:有效的地點 ID。有效的位置識別碼包括:us-west1us-east1europe-west1asia-east1
  • DISPLAY_NAME:您選擇的字串顯示名稱。
  • PRODUCT_DESCRIPTION:您選擇的字串說明。
  • product-category:有效的產品類別。目前可用的產品類別如下:homegoods-v2apparel-v2toys-v2packagedgoods-v1general-v1
  • productLabels:與產品相關聯的一或多個鍵/值組合。每個 KEY_STRING 都必須有相關聯的 VALUE_STRING

HTTP 方法和網址:

POST https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products

JSON 要求主體:

{
  "displayName": "display-name",
  "description": "product-description",
  "productCategory": "product-category",
  "productLabels": [
      {
        "key": "key-string",
        "value": "value-string"
      }
  ]
}

如要傳送要求,請選擇以下其中一個選項:

curl

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

curl -X POST \
-H "Authorization: Bearer $(gcloud auth print-access-token)" \
-H "x-goog-user-project: project-id" \
-H "Content-Type: application/json; charset=utf-8" \
-d @request.json \
"https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products"

PowerShell

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred"; "x-goog-user-project" = "project-id" }

Invoke-WebRequest `
-Method POST `
-Headers $headers `
-ContentType: "application/json; charset=utf-8" `
-InFile request.json `
-Uri "https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products" | Select-Object -Expand Content

要求主體範例:

{
  "displayName": "sample-product-1234",
  "description": "Athletic shorts",
  "productCategory": "apparel-v2",
  "productLabels": [
      {
        "key": "style",
        "value": "womens"
      },
      {
        "key": "color",
        "value": "blue"
      }
  ]
}

如果要求成功,伺服器會傳回 200 OK HTTP 狀態碼與 JSON 格式的回應。

畫面會顯示類似以下的輸出。您可以使用產品 ID (本例中為 37b9811d308c4e42) 對產品執行其他作業。

{
  "name": "projects/project-id/locations/location-id/products/37b9811d308c4e42",
  "displayName": "sample-product-456",
  "description": "Athletic shorts",
  "productCategory": "apparel-v2",
  "productLabels": [
    {
      "key": "style",
      "value": "womens"
    },
    {
      "key": "color",
      "value": "blue"
    }
  ]
}

Go

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Go API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


import (
	"context"
	"fmt"
	"io"

	vision "cloud.google.com/go/vision/apiv1"
	"cloud.google.com/go/vision/v2/apiv1/visionpb"
)

// createProduct creates a product.
func createProduct(w io.Writer, projectID string, location string, productID string, productDisplayName string, productCategory string) error {
	ctx := context.Background()
	c, err := vision.NewProductSearchClient(ctx)
	if err != nil {
		return fmt.Errorf("NewProductSearchClient: %w", err)
	}
	defer c.Close()

	req := &visionpb.CreateProductRequest{
		Parent:    fmt.Sprintf("projects/%s/locations/%s", projectID, location),
		ProductId: productID,
		Product: &visionpb.Product{
			DisplayName:     productDisplayName,
			ProductCategory: productCategory,
		},
	}

	resp, err := c.CreateProduct(ctx, req)
	if err != nil {
		return fmt.Errorf("CreateProduct: %w", err)
	}

	fmt.Fprintf(w, "Product name: %s\n", resp.Name)

	return nil
}

Java

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Java API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

/**
 * Create one product.
 *
 * @param projectId - Id of the project.
 * @param computeRegion - Region name.
 * @param productId - Id of the product.
 * @param productDisplayName - Display name of the product.
 * @param productCategory - Category of the product.
 * @throws IOException - on I/O errors.
 */
public static void createProduct(
    String projectId,
    String computeRegion,
    String productId,
    String productDisplayName,
    String productCategory)
    throws IOException {
  try (ProductSearchClient client = ProductSearchClient.create()) {

    // A resource that represents Google Cloud Platform location.
    String formattedParent = LocationName.format(projectId, computeRegion);
    // Create a product with the product specification in the region.
    // Multiple labels are also supported.
    Product myProduct =
        Product.newBuilder()
            .setName(productId)
            .setDisplayName(productDisplayName)
            .setProductCategory(productCategory)
            .build();
    Product product = client.createProduct(formattedParent, myProduct, productId);
    // Display the product information
    System.out.println(String.format("Product name: %s", product.getName()));
  }
}

Node.js

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Node.js API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

// Imports the Google Cloud client library
const vision = require('@google-cloud/vision');

// Creates a client
const client = new vision.ProductSearchClient();
async function createProduct() {
  /**
   * TODO(developer): Uncomment the following line before running the sample.
   */
  // const projectId = 'Your Google Cloud project Id';
  // const location = 'A compute region name';
  // const productId = 'Id of the product';
  // const productDisplayName = 'Display name of the product';
  // const productCategory = 'Catoegory of the product';

  // Resource path that represents Google Cloud Platform location.
  const locationPath = client.locationPath(projectId, location);

  const product = {
    displayName: productDisplayName,
    productCategory: productCategory,
  };

  const request = {
    parent: locationPath,
    product: product,
    productId: productId,
  };

  const [createdProduct] = await client.createProduct(request);
  console.log(`Product name: ${createdProduct.name}`);
}
createProduct();

Python

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Python API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

from google.cloud import vision
from google.protobuf import field_mask_pb2 as field_mask

def create_product(
    project_id, location, product_id, product_display_name, product_category
):
    """Create one product.
    Args:
        project_id: Id of the project.
        location: A compute region name.
        product_id: Id of the product.
        product_display_name: Display name of the product.
        product_category: Category of the product.
    """
    client = vision.ProductSearchClient()

    # A resource that represents Google Cloud Platform location.
    location_path = f"projects/{project_id}/locations/{location}"

    # Create a product with the product specification in the region.
    # Set product display name and product category.
    product = vision.Product(
        display_name=product_display_name, product_category=product_category
    )

    # The response is the product with the `name` field populated.
    response = client.create_product(
        parent=location_path, product=product, product_id=product_id
    )

    # Display the product information.
    print(f"Product name: {response.name}")


其他語言

C#: 請按照用戶端程式庫頁面的 C# 設定說明操作, 然後前往 .NET 適用的 Vision API Product Search 參考說明文件

PHP: 請按照用戶端程式庫頁面上的 PHP 設定說明 操作,然後前往 PHP 適用的 Vision API 產品搜尋參考文件

Ruby: 請按照用戶端程式庫頁面的 Ruby 設定說明操作, 然後前往 Ruby 適用的 Vision API Product Search 參考說明文件

回應

Product name: projects/prj-prod-search-tutorials/locations/us-east1/products/P_CLOTH-SHOE_46903668_070318
Product id: P_CLOTH-SHOE_46903668_070318
Product display name: Blue Dress
Product category: apparel
Product description: Short sleeved and 1950s style satin dress
Product labels:
  Product label 1:
        key: style
        value: women
  Product label 2:
        key: category
        value: dress
  Product label 3:
        key: color
        value: dark-blue

3. 將產品新增至產品集

建立產品組合和產品後,即可將產品加入產品組合。

REST

使用任何要求資料之前,請先替換以下項目:

  • PROJECT_ID:您的 Google Cloud 專案 ID。
  • LOCATION_ID:有效的地點 ID。有效的位置識別碼包括:us-west1us-east1europe-west1asia-east1
  • PRODUCT_SET_ID:要對其執行作業的產品組合 ID。
  • PRODUCT_NAME:產品的完整資源名稱。 格式:
    • projects/PROJECT_ID/locations/LOCATION_ID/products/PRODUCT_ID

HTTP 方法和網址:

POST https://vision.googleapis.com/v1/projects/project-id/locations/location-id/productSets/product-set-id:addProduct

JSON 要求主體:

{
  "product": "product-name"
}

如要傳送要求,請選擇以下其中一個選項:

curl

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

curl -X POST \
-H "Authorization: Bearer $(gcloud auth print-access-token)" \
-H "x-goog-user-project: project-id" \
-H "Content-Type: application/json; charset=utf-8" \
-d @request.json \
"https://vision.googleapis.com/v1/projects/project-id/locations/location-id/productSets/product-set-id:addProduct"

PowerShell

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred"; "x-goog-user-project" = "project-id" }

Invoke-WebRequest `
-Method POST `
-Headers $headers `
-ContentType: "application/json; charset=utf-8" `
-InFile request.json `
-Uri "https://vision.googleapis.com/v1/projects/project-id/locations/location-id/productSets/product-set-id:addProduct" | Select-Object -Expand Content

您應該會收到如下的 JSON 回應:

{}

Go

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Go API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


import (
	"context"
	"fmt"
	"io"

	vision "cloud.google.com/go/vision/apiv1"
	"cloud.google.com/go/vision/v2/apiv1/visionpb"
)

// addProductToProductSet adds a product to a product set.
func addProductToProductSet(w io.Writer, projectID string, location string, productID string, productSetID string) error {
	ctx := context.Background()
	c, err := vision.NewProductSearchClient(ctx)
	if err != nil {
		return fmt.Errorf("NewProductSearchClient: %w", err)
	}
	defer c.Close()

	req := &visionpb.AddProductToProductSetRequest{
		Name:    fmt.Sprintf("projects/%s/locations/%s/productSets/%s", projectID, location, productSetID),
		Product: fmt.Sprintf("projects/%s/locations/%s/products/%s", projectID, location, productID),
	}

	if err = c.AddProductToProductSet(ctx, req); err != nil {
		return fmt.Errorf("NewProductSearchClient: %w", err)
	}

	fmt.Fprintf(w, "Product added to product set.\n")

	return nil
}

Java

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Java API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


/**
 * Add a product to a product set.
 *
 * @param projectId - Id of the project.
 * @param computeRegion - Region name.
 * @param productId - Id of the product.
 * @param productSetId - Id of the product set.
 * @throws IOException - on I/O errors.
 */
public static void addProductToProductSet(
    String projectId, String computeRegion, String productId, String productSetId)
    throws IOException {
  try (ProductSearchClient client = ProductSearchClient.create()) {

    // Get the full path of the product set.
    String formattedName = ProductSetName.format(projectId, computeRegion, productSetId);

    // Get the full path of the product.
    String productPath = ProductName.of(projectId, computeRegion, productId).toString();

    // Add the product to the product set.
    client.addProductToProductSet(formattedName, productPath);

    System.out.println(String.format("Product added to product set."));
  }
}

Node.js

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Node.js API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

const vision = require('@google-cloud/vision');
const client = new vision.ProductSearchClient();

async function addProductToProductSet() {
  /**
   * TODO(developer): Uncomment the following line before running the sample.
   */
  // const projectId = 'Your Google Cloud project Id';
  // const location = 'A compute region name';
  // const productId = 'Id of the product';
  // const productSetId = 'Id of the product set';

  const productPath = client.productPath(projectId, location, productId);
  const productSetPath = client.productSetPath(
    projectId,
    location,
    productSetId
  );

  const request = {
    name: productSetPath,
    product: productPath,
  };

  await client.addProductToProductSet(request);
  console.log('Product added to product set.');
}
addProductToProductSet();

Python

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Python API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

from google.cloud import vision

def add_product_to_product_set(project_id, location, product_id, product_set_id):
    """Add a product to a product set.
    Args:
        project_id: Id of the project.
        location: A compute region name.
        product_id: Id of the product.
        product_set_id: Id of the product set.
    """
    client = vision.ProductSearchClient()

    # Get the full path of the product set.
    product_set_path = client.product_set_path(
        project=project_id, location=location, product_set=product_set_id
    )

    # Get the full path of the product.
    product_path = client.product_path(
        project=project_id, location=location, product=product_id
    )

    # Add the product to the product set.
    client.add_product_to_product_set(name=product_set_path, product=product_path)
    print("Product added to product set.")


其他語言

C#: 請按照用戶端程式庫頁面的 C# 設定說明操作, 然後前往 .NET 適用的 Vision API Product Search 參考說明文件

PHP: 請按照用戶端程式庫頁面上的 PHP 設定說明 操作,然後前往 PHP 適用的 Vision API 產品搜尋參考文件

Ruby: 請按照用戶端程式庫頁面的 Ruby 設定說明操作, 然後前往 Ruby 適用的 Vision API Product Search 參考說明文件

回應

Product added to product set.

4. 更新產品

如要在建立產品或產品組合後更新,可以使用我們的更新方法。這個範例顯示產品更新,其中標籤已變更:

指令列

傳送 PATCH 要求時,系統會清除所有先前的欄位及其值,但 productCategory 欄位除外,因為該欄位不可變更。送出 PATCH 更新要求時,請一併傳送所有必要欄位及其值。

使用任何要求資料之前,請先替換以下項目:

  • PROJECT_ID:您的 Google Cloud 專案 ID。
  • LOCATION_ID:有效的地點 ID。有效的位置識別碼包括:us-west1us-east1europe-west1asia-east1
  • PRODUCT_ID:與參考圖片相關聯的產品 ID。這個 ID 是隨機設定,或由使用者在建立產品時指定。
  • display-name:您選擇的字串顯示名稱。這個值可以與先前的顯示名稱相同,也可以是更新後的值。
  • description:您選擇的字串說明。這可以與先前的顯示名稱相同,也可以是更新的值。如不需要,請省略 description 欄位和值。
  • productLabels:與產品相關聯的一或多個鍵/值組合。每個 KEY_STRING 都必須有相關聯的 VALUE_STRING

HTTP 方法和網址:

PATCH https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products/product-id

JSON 要求主體:

{
  "displayName": "display-name",
  "description": "description",
  "productLabels": [
    {
      "key": "key-string",
      "value": "value-string"
    },
    {
      "key": "key-string",
      "value": "value-string"
    }
  ]
}

如要傳送要求,請選擇以下其中一個選項:

curl

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

curl -X PATCH \
-H "Authorization: Bearer $(gcloud auth print-access-token)" \
-H "x-goog-user-project: project-id" \
-H "Content-Type: application/json; charset=utf-8" \
-d @request.json \
"https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products/product-id"

PowerShell

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred"; "x-goog-user-project" = "project-id" }

Invoke-WebRequest `
-Method PATCH `
-Headers $headers `
-ContentType: "application/json; charset=utf-8" `
-InFile request.json `
-Uri "https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products/product-id" | Select-Object -Expand Content

您應該會收到如下的 JSON 回應:

{
  "name": "projects/project-id/locations/location-id/products/product-id",
  "displayName": "display-name",
  "description": "description",
  "productCategory": "apparel-v2",
  "productLabels": [
    {
      "key": "style",
      "value": "womens"
    },
    {
      "key": "onSale",
      "value": "true"
    }
  ]
}

Go

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Go API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


import (
	"context"
	"fmt"
	"io"

	vision "cloud.google.com/go/vision/apiv1"
	"cloud.google.com/go/vision/v2/apiv1/visionpb"
	field_mask "google.golang.org/genproto/protobuf/field_mask"
)

// updateProductLabels updates product labels of a product.
func updateProductLabels(w io.Writer, projectID string, location string, productID string, key string, value string) error {
	ctx := context.Background()
	c, err := vision.NewProductSearchClient(ctx)
	if err != nil {
		return fmt.Errorf("NewProductSearchClient: %w", err)
	}
	defer c.Close()

	req := &visionpb.UpdateProductRequest{
		UpdateMask: &field_mask.FieldMask{
			Paths: []string{
				"product_labels",
			},
		},
		Product: &visionpb.Product{
			Name: fmt.Sprintf("projects/%s/locations/%s/products/%s", projectID, location, productID),
			ProductLabels: []*visionpb.Product_KeyValue{
				{
					Key:   key,
					Value: value,
				},
			},
		},
	}

	resp, err := c.UpdateProduct(ctx, req)
	if err != nil {
		return fmt.Errorf("UpdateProduct: %w", err)
	}

	fmt.Fprintf(w, "Product name: %s\n", resp.Name)
	fmt.Fprintf(w, "Updated product labels: %s\n", resp.ProductLabels)

	return nil
}

Java

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Java API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

/**
 * Update the product labels.
 *
 * @param projectId - Id of the project.
 * @param computeRegion - Region name.
 * @param productId -Id of the product.
 * @param productLabels - Labels of the product.
 * @throws IOException - on I/O errors.
 */
public static void updateProductLabels(
    String projectId, String computeRegion, String productId, String productLabels)
    throws IOException {
  try (ProductSearchClient client = ProductSearchClient.create()) {

    // Get the full path of the product.
    String formattedName = ProductName.format(projectId, computeRegion, productId);

    // Set product name, product labels and product display name.
    // Multiple labels are also supported.
    Product product =
        Product.newBuilder()
            .setName(formattedName)
            .addProductLabels(
                KeyValue.newBuilder()
                    .setKey(productLabels.split(",")[0].split("=")[0])
                    .setValue(productLabels.split(",")[0].split("=")[1])
                    .build())
            .build();

    // Set product update field name.
    FieldMask updateMask = FieldMask.newBuilder().addPaths("product_labels").build();

    // Update the product.
    Product updatedProduct = client.updateProduct(product, updateMask);
    // Display the product information
    System.out.println(String.format("Product name: %s", updatedProduct.getName()));
    System.out.println(String.format("Updated product labels: "));
    for (Product.KeyValue element : updatedProduct.getProductLabelsList()) {
      System.out.println(String.format("%s: %s", element.getKey(), element.getValue()));
    }
  }
}

Node.js

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Node.js API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

// Imports the Google Cloud client library
const vision = require('@google-cloud/vision');

// Creates a client
const client = new vision.ProductSearchClient();

async function updateProductLabels() {
  /**
   * TODO(developer): Uncomment the following line before running the sample.
   */
  // const projectId = 'Your Google Cloud project Id';
  // const location = 'A compute region name';
  // const productId = 'Id of the product';
  // const key = 'The key of the label';
  // const value = 'The value of the label';

  // Resource path that represents full path to the product.
  const productPath = client.productPath(projectId, location, productId);

  const product = {
    name: productPath,
    productLabels: [
      {
        key: key,
        value: value,
      },
    ],
  };

  const updateMask = {
    paths: ['product_labels'],
  };

  const request = {
    product: product,
    updateMask: updateMask,
  };

  const [updatedProduct] = await client.updateProduct(request);
  console.log(`Product name: ${updatedProduct.name}`);
  console.log(`Product display name: ${updatedProduct.displayName}`);
  console.log(`Product description: ${updatedProduct.description}`);
  console.log(`Product category: ${updatedProduct.productCategory}`);
  console.log(
    `Product Labels: ${updatedProduct.productLabels[0].key}: ${updatedProduct.productLabels[0].value}`
  );
}
updateProductLabels();

Python

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Python API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

from google.cloud import vision
from google.protobuf import field_mask_pb2 as field_mask

def update_product_labels(project_id, location, product_id, key, value):
    """Update the product labels.
    Args:
        project_id: Id of the project.
        location: A compute region name.
        product_id: Id of the product.
        key: The key of the label.
        value: The value of the label.
    """
    client = vision.ProductSearchClient()

    # Get the name of the product.
    product_path = client.product_path(
        project=project_id, location=location, product=product_id
    )

    # Set product name, product label and product display name.
    # Multiple labels are also supported.
    key_value = vision.Product.KeyValue(key=key, value=value)
    product = vision.Product(name=product_path, product_labels=[key_value])

    # Updating only the product_labels field here.
    update_mask = field_mask.FieldMask(paths=["product_labels"])

    # This overwrites the product_labels.
    updated_product = client.update_product(product=product, update_mask=update_mask)

    # Display the updated product information.
    print(f"Product name: {updated_product.name}")
    print(f"Updated product labels: {product.product_labels}")


其他語言

C#: 請按照用戶端程式庫頁面的 C# 設定說明操作, 然後前往 .NET 適用的 Vision API Product Search 參考說明文件

PHP: 請按照用戶端程式庫頁面上的 PHP 設定說明 操作,然後前往 PHP 適用的 Vision API 產品搜尋參考文件

Ruby: 請按照用戶端程式庫頁面的 Ruby 設定說明操作, 然後前往 Ruby 適用的 Vision API Product Search 參考說明文件

回應

Product name: projects/prj-prod-search-tutorials/locations/us-east1/products/P_CLOTH-SHOE_46903668_070318
Product id: P_CLOTH-SHOE_46903668_070318
Product display name: Blue Dress
Updated product labels:
  Product label 1:
        key: style
        value: women
  Product label 2:
        key: category
        value: dress
  Product label 3:
        key: color
        value: blue
Product description: Short sleeved and 1950s style satin dress

5. 建立產品的參考圖片

為個別產品建立參考圖片後,Vision API Product Search 就能在建立索引後,透過這張圖片搜尋產品。產品可以有多張參考圖片,特別是如果希望獲得更優質的相符結果。

你隨時可以為產品新增參考圖片。

建立參照圖片時,您可以選擇加入邊界多邊形座標。邊界多邊形會識別參考圖片中的感興趣區域。舉例來說,如果您為外套產品建立參考圖片,可以在 bounding poly 參數中提供外套的座標,系統就會在尋找相符產品時只考慮外套。注意:您可以在建立索引時提供多個邊界多邊形,但查詢時 API 只支援單一邊界多邊形。

如要取得圖片的定界多邊形座標,最簡單的方法是使用 Vision API 物件定位功能。如要進一步瞭解物件定位,請參閱「偵測多個物件」。

REST

使用任何要求資料之前,請先替換以下項目:

  • PROJECT_ID:您的 Google Cloud 專案 ID。
  • LOCATION_ID:有效的地點 ID。有效的位置識別碼包括:us-west1us-east1europe-west1asia-east1
  • PRODUCT_ID:與參考圖片相關聯的產品 ID。這個 ID 是隨機設定,或由使用者在建立產品時指定。
  • CLOUD_STORAGE_IMAGE_URI:Cloud Storage 值區中有效圖片檔案的路徑。您必須至少擁有檔案的讀取權限。 範例:
    • gs://storage-bucket/filename.jpg

HTTP 方法和網址:

POST https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products/product-id/referenceImages

JSON 要求主體:

{
  "uri": "cloud-storage-image-uri",
  "boundingPolys": [
    {
      "vertices": [
        {
          "x": X_MIN,
          "y": Y_MIN
        },
        {
          "x": X_MAX,
          "y": Y_MIN
        },
        {
          "x": X_MAX,
          "y": Y_MAX
        },
        {
          "x": X_MIN,
          "y": Y_MAX
        }
      ]
    }
  ]
}

如要傳送要求,請選擇以下其中一個選項:

curl

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

curl -X POST \
-H "Authorization: Bearer $(gcloud auth print-access-token)" \
-H "x-goog-user-project: project-id" \
-H "Content-Type: application/json; charset=utf-8" \
-d @request.json \
"https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products/product-id/referenceImages"

PowerShell

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred"; "x-goog-user-project" = "project-id" }

Invoke-WebRequest `
-Method POST `
-Headers $headers `
-ContentType: "application/json; charset=utf-8" `
-InFile request.json `
-Uri "https://vision.googleapis.com/v1/projects/project-id/locations/location-id/products/product-id/referenceImages" | Select-Object -Expand Content

如果要求成功,伺服器會傳回 200 OK HTTP 狀態碼與 JSON 格式的回應。

畫面會顯示類似以下的輸出。範例要求在圖片中指定了單一 boundingPoly。定界框的頂點不會經過正規化,頂點值是實際像素值,不會與原始圖片相關,也不會縮放為 0 到 1。這些頂點的值如下:[(33,22),(282,22),(282,278),(33,278)]。


{
  "name": "projects/project-id/locations/location-id/products/product-id/referenceImages/image-id",
  "uri": "gs://storage-bucket/filename.jpg",
  "boundingPolys": [
    {
      "vertices": [
        {
          "x": 33,
          "y": 22
        },
        {
          "x": 282,
          "y": 22
        },
        {
          "x": 282,
          "y": 278
        },
        {
          "x": 33,
          "y": 278
        }
      ]
    }
  ]
}

Go

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Go API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


import (
	"context"
	"fmt"
	"io"

	vision "cloud.google.com/go/vision/apiv1"
	"cloud.google.com/go/vision/v2/apiv1/visionpb"
)

// createReferenceImage creates a reference image for a product.
func createReferenceImage(w io.Writer, projectID string, location string, productID string, referenceImageID string, gcsURI string) error {
	ctx := context.Background()
	c, err := vision.NewProductSearchClient(ctx)
	if err != nil {
		return fmt.Errorf("NewProductSearchClient: %w", err)
	}
	defer c.Close()

	req := &visionpb.CreateReferenceImageRequest{
		Parent: fmt.Sprintf("projects/%s/locations/%s/products/%s", projectID, location, productID),
		ReferenceImage: &visionpb.ReferenceImage{
			Uri: gcsURI,
		},
		ReferenceImageId: referenceImageID,
	}

	resp, err := c.CreateReferenceImage(ctx, req)
	if err != nil {
		return fmt.Errorf("CreateReferenceImage: %w", err)
	}

	fmt.Fprintf(w, "Reference image name: %s\n", resp.Name)
	fmt.Fprintf(w, "Reference image uri: %s\n", resp.Uri)

	return nil
}

Java

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Java API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

/**
 * Create a reference image.
 *
 * @param projectId - Id of the project.
 * @param computeRegion - Region name.
 * @param productId - Id of the product.
 * @param referenceImageId - Id of the image.
 * @param gcsUri - Google Cloud Storage path of the input image.
 * @throws IOException - on I/O errors.
 */
public static void createReferenceImage(
    String projectId,
    String computeRegion,
    String productId,
    String referenceImageId,
    String gcsUri)
    throws IOException {
  try (ProductSearchClient client = ProductSearchClient.create()) {

    // Get the full path of the product.
    String formattedParent = ProductName.format(projectId, computeRegion, productId);
    // Create a reference image.
    ReferenceImage referenceImage = ReferenceImage.newBuilder().setUri(gcsUri).build();

    ReferenceImage image =
        client.createReferenceImage(formattedParent, referenceImage, referenceImageId);
    // Display the reference image information.
    System.out.println(String.format("Reference image name: %s", image.getName()));
    System.out.println(String.format("Reference image uri: %s", image.getUri()));
  }
}

Node.js

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Node.js API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

const vision = require('@google-cloud/vision');

const client = new vision.ProductSearchClient();

async function createReferenceImage() {
  /**
   * TODO(developer): Uncomment the following line before running the sample.
   */
  // const projectId = 'Your Google Cloud project Id';
  // const location = 'A compute region name';
  // const productId = 'Id of the product';
  // const referenceImageId = 'Id of the reference image';
  // const gcsUri = 'Google Cloud Storage path of the input image';

  const formattedParent = client.productPath(projectId, location, productId);

  const referenceImage = {
    uri: gcsUri,
  };

  const request = {
    parent: formattedParent,
    referenceImage: referenceImage,
    referenceImageId: referenceImageId,
  };

  const [response] = await client.createReferenceImage(request);
  console.log(`response.name: ${response.name}`);
  console.log(`response.uri: ${response.uri}`);
}
createReferenceImage();

Python

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Python API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

from google.cloud import vision

def create_reference_image(
    project_id, location, product_id, reference_image_id, gcs_uri
):
    """Create a reference image.
    Args:
        project_id: Id of the project.
        location: A compute region name.
        product_id: Id of the product.
        reference_image_id: Id of the reference image.
        gcs_uri: Google Cloud Storage path of the input image.
    """
    client = vision.ProductSearchClient()

    # Get the full path of the product.
    product_path = client.product_path(
        project=project_id, location=location, product=product_id
    )

    # Create a reference image.
    reference_image = vision.ReferenceImage(uri=gcs_uri)

    # The response is the reference image with `name` populated.
    image = client.create_reference_image(
        parent=product_path,
        reference_image=reference_image,
        reference_image_id=reference_image_id,
    )

    # Display the reference image information.
    print(f"Reference image name: {image.name}")
    print(f"Reference image uri: {image.uri}")


其他語言

C#: 請按照用戶端程式庫頁面的 C# 設定說明操作, 然後前往 .NET 適用的 Vision API Product Search 參考說明文件

PHP: 請按照用戶端程式庫頁面上的 PHP 設定說明 操作,然後前往 PHP 適用的 Vision API 產品搜尋參考文件

Ruby: 請按照用戶端程式庫頁面的 Ruby 設定說明操作, 然後前往 Ruby 適用的 Vision API Product Search 參考說明文件

回應

Reference image name: projects/prj-prod-search-tutorials/locations/us-east1/products/P_CLOTH-SHOE_46903668_070318/referenceImages/I_469a896b70ba11e8be97d20059124800_070418
Reference image id: I_469a896b70ba11e8be97d20059124800_070418
Reference image uri: gs://product-search-tutorial/dress-shoe-dataset/469a896b70ba11e8be97d20059124800.jpg
Reference image bounding polygons:
vertices {
  x: 80
  y: 50
}
vertices {
  x: 80
  y: 660
}
vertices {
  x: 300
  y: 50
}
vertices {
  x: 430
  y: 660
}

步驟 2:搜尋相符的產品

這個介面可讓您查詢建立的產品目錄,方法是輸入新圖片並搜尋最相符的產品。

與建立參考圖片類似,搜尋相符圖片時,您可以選擇加入定界多邊形座標。邊界多邊形會識別來源圖片中您要尋找相符項目的感興趣區域。舉例來說,如果來源圖片同時包含洋裝和皮夾,但您只想尋找洋裝的相符項目,可以找出只包含洋裝的圖片區域的邊界多邊形座標。根據預設,如果未指定任何邊界多邊形,API 會判斷最大的邊界多邊形,並自動查詢。

如要取得圖片的定界多邊形座標,最簡單的方法是使用 Vision API 物件定位功能。如要進一步瞭解物件定位,請參閱「偵測多個物件」。舉例來說,您可以指定整個圖片方塊的定界多邊形:[(0, 0), (0, 1), (1, 1), (1, 0)],明確查詢完整圖片。

要求會傳回 API 回應,其中包含圖片的最佳相符產品、分數和相符圖片。系統會傳回可信度最高的值。

REST

使用任何要求資料之前,請先替換以下項目:

  • BASE64_ENCODED_IMAGE:二進位圖片資料的 Base64 表示法 (ASCII 字串)。這個字串應類似下列字串:
    • /9j/4QAYRXhpZgAA...9tAVx/zDQDlGxn//2Q==
    詳情請參閱 base64 編碼主題。
  • PROJECT_ID:您的 Google Cloud 專案 ID。
  • LOCATION_ID:有效的地點 ID。有效的位置識別碼包括:us-west1us-east1europe-west1asia-east1
  • PRODUCT_SET_ID:要對其執行作業的產品組合 ID。

欄位專屬注意事項:

  • features.maxResults - 要傳回的結果數上限。
  • imageContext.productCategories - 要搜尋的產品類別。目前只能指定一個產品類別 (居家用品、服飾、玩具、民生消費用品和一般用品)。
  • imageContext.filter - (選用) 產品標籤的鍵/值篩選運算式 (或多個運算式)。格式:「key=value」。篩選鍵/值組合時,可使用 AND 或 OR 運算式連結:「color=blue AND style=mens」或「color=blue OR color=black」。如果使用 OR 運算式,運算式中的所有鍵都必須相同

HTTP 方法和網址:

POST https://vision.googleapis.com/v1/images:annotate

JSON 要求主體:

{
  "requests": [
    {
      "image": {
        "content": base64-encoded-image
      },
      "features": [
        {
          "type": "PRODUCT_SEARCH",
          "maxResults": 5
        }
      ],
      "imageContext": {
        "productSearchParams": {
          "productSet": "projects/project-id/locations/location-id/productSets/product-set-id",
          "productCategories": [
               "apparel"
          ],
          "filter": "style = womens"
        }
      }
    }
  ]
}

如要傳送要求,請選擇以下其中一個選項:

curl

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

curl -X POST \
-H "Authorization: Bearer $(gcloud auth print-access-token)" \
-H "x-goog-user-project: project-id" \
-H "Content-Type: application/json; charset=utf-8" \
-d @request.json \
"https://vision.googleapis.com/v1/images:annotate"

PowerShell

將要求主體儲存在名為 request.json 的檔案中,然後執行下列指令:

$cred = gcloud auth print-access-token
$headers = @{ "Authorization" = "Bearer $cred"; "x-goog-user-project" = "project-id" }

Invoke-WebRequest `
-Method POST `
-Headers $headers `
-ContentType: "application/json; charset=utf-8" `
-InFile request.json `
-Uri "https://vision.googleapis.com/v1/images:annotate" | Select-Object -Expand Content

如果要求成功,伺服器會傳回 200 OK HTTP 狀態碼與 JSON 格式的回應。

回應 JSON 包含下列兩種結果類型:

  • productSearchResults:包含整張圖片的相符產品清單。在範例回應中,相符的產品為:product_id65、 product_id35、product_id34、product_id62、 product_id32。
  • productGroupedResults - 包含圖片中識別出的各項產品的定界框座標和相符項目。在下列回應中,系統只識別出一個產品,接著是範例產品集中相符的產品:product_id65、product_id35、product_id34、product_id93、product_id62。

請注意,雖然這兩種結果類型有重疊之處,但也可能存在差異 (例如回應中的 product_id32 和 product_id93)。

Go

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Go API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。


import (
	"context"
	"fmt"
	"io"
	"os"

	vision "cloud.google.com/go/vision/apiv1"
	"cloud.google.com/go/vision/v2/apiv1/visionpb"
)

// getSimilarProducts searches for products from a product set similar to products in an image file.
func getSimilarProducts(w io.Writer, projectID string, location string, productSetID string, productCategory string, file string, filter string) error {
	ctx := context.Background()
	c, err := vision.NewImageAnnotatorClient(ctx)
	if err != nil {
		return fmt.Errorf("NewImageAnnotatorClient: %w", err)
	}
	defer c.Close()

	f, err := os.Open(file)
	if err != nil {
		return fmt.Errorf("Open: %w", err)
	}
	defer f.Close()

	image, err := vision.NewImageFromReader(f)
	if err != nil {
		return fmt.Errorf("NewImageFromReader: %w", err)
	}

	ictx := &visionpb.ImageContext{
		ProductSearchParams: &visionpb.ProductSearchParams{
			ProductSet:        fmt.Sprintf("projects/%s/locations/%s/productSets/%s", projectID, location, productSetID),
			ProductCategories: []string{productCategory},
			Filter:            filter,
		},
	}

	response, err := c.ProductSearch(ctx, image, ictx)
	if err != nil {
		return fmt.Errorf("ProductSearch: %w", err)
	}

	fmt.Fprintf(w, "Product set index time:\n")
	fmt.Fprintf(w, "seconds: %d\n", response.IndexTime.Seconds)
	fmt.Fprintf(w, "nanos: %d\n", response.IndexTime.Nanos)

	fmt.Fprintf(w, "Search results:\n")
	for _, result := range response.Results {
		fmt.Fprintf(w, "Score(Confidence): %f\n", result.Score)
		fmt.Fprintf(w, "Image name: %s\n", result.Image)

		fmt.Fprintf(w, "Prodcut name: %s\n", result.Product.Name)
		fmt.Fprintf(w, "Product display name: %s\n", result.Product.DisplayName)
		fmt.Fprintf(w, "Product labels: %s\n", result.Product.ProductLabels)
	}

	return nil
}

Java

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Java API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

/**
 * Search similar products to image in local file.
 *
 * @param projectId - Id of the project.
 * @param computeRegion - Region name.
 * @param productSetId - Id of the product set.
 * @param productCategory - Category of the product.
 * @param filePath - Local file path of the image to be searched
 * @param filter - Condition to be applied on the labels. Example for filter: (color = red OR
 *     color = blue) AND style = kids It will search on all products with the following labels:
 *     color:red AND style:kids color:blue AND style:kids
 * @throws IOException - on I/O errors.
 */
public static void getSimilarProductsFile(
    String projectId,
    String computeRegion,
    String productSetId,
    String productCategory,
    String filePath,
    String filter)
    throws IOException {
  try (ImageAnnotatorClient queryImageClient = ImageAnnotatorClient.create()) {

    // Get the full path of the product set.
    String productSetPath = ProductSetName.format(projectId, computeRegion, productSetId);

    // Read the image as a stream of bytes.
    File imgPath = new File(filePath);
    byte[] content = Files.readAllBytes(imgPath.toPath());

    // Create annotate image request along with product search feature.
    Feature featuresElement = Feature.newBuilder().setType(Type.PRODUCT_SEARCH).build();
    // The input image can be a HTTPS link or Raw image bytes.
    // Example:
    // To use HTTP link replace with below code
    //  ImageSource source = ImageSource.newBuilder().setImageUri(imageUri).build();
    //  Image image = Image.newBuilder().setSource(source).build();
    Image image = Image.newBuilder().setContent(ByteString.copyFrom(content)).build();
    ImageContext imageContext =
        ImageContext.newBuilder()
            .setProductSearchParams(
                ProductSearchParams.newBuilder()
                    .setProductSet(productSetPath)
                    .addProductCategories(productCategory)
                    .setFilter(filter))
            .build();

    AnnotateImageRequest annotateImageRequest =
        AnnotateImageRequest.newBuilder()
            .addFeatures(featuresElement)
            .setImage(image)
            .setImageContext(imageContext)
            .build();
    List<AnnotateImageRequest> requests = Arrays.asList(annotateImageRequest);

    // Search products similar to the image.
    BatchAnnotateImagesResponse response = queryImageClient.batchAnnotateImages(requests);

    List<Result> similarProducts =
        response.getResponses(0).getProductSearchResults().getResultsList();
    System.out.println("Similar Products: ");
    for (Result product : similarProducts) {
      System.out.println(String.format("\nProduct name: %s", product.getProduct().getName()));
      System.out.println(
          String.format("Product display name: %s", product.getProduct().getDisplayName()));
      System.out.println(
          String.format("Product description: %s", product.getProduct().getDescription()));
      System.out.println(String.format("Score(Confidence): %s", product.getScore()));
      System.out.println(String.format("Image name: %s", product.getImage()));
    }
  }
}

Node.js

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Node.js API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

// Imports the Google Cloud client library
const vision = require('@google-cloud/vision');
const fs = require('fs');
// Creates a client
const productSearchClient = new vision.ProductSearchClient();
const imageAnnotatorClient = new vision.ImageAnnotatorClient();

async function getSimilarProductsFile() {
  /**
   * TODO(developer): Uncomment the following line before running the sample.
   */
  // const projectId = 'nodejs-docs-samples';
  // const location = 'us-west1';
  // const productSetId = 'indexed_product_set_id_for_testing';
  // const productCategory = 'apparel';
  // const filePath = './resources/shoes_1.jpg';
  // const filter = '';
  const productSetPath = productSearchClient.productSetPath(
    projectId,
    location,
    productSetId
  );
  const content = fs.readFileSync(filePath, 'base64');
  const request = {
    // The input image can be a GCS link or HTTPS link or Raw image bytes.
    // Example:
    // To use GCS link replace with below code
    // image: {source: {gcsImageUri: filePath}}
    // To use HTTP link replace with below code
    // image: {source: {imageUri: filePath}}
    image: {content: content},
    features: [{type: 'PRODUCT_SEARCH'}],
    imageContext: {
      productSearchParams: {
        productSet: productSetPath,
        productCategories: [productCategory],
        filter: filter,
      },
    },
  };
  const [response] = await imageAnnotatorClient.batchAnnotateImages({
    requests: [request],
  });
  console.log('Search Image:', filePath);
  const results = response['responses'][0]['productSearchResults']['results'];
  console.log('\nSimilar product information:');
  results.forEach(result => {
    console.log('Product id:', result['product'].name.split('/').pop(-1));
    console.log('Product display name:', result['product'].displayName);
    console.log('Product description:', result['product'].description);
    console.log('Product category:', result['product'].productCategory);
  });
}
getSimilarProductsFile();

Python

如要瞭解如何安裝及使用 Vision API Product Search 的用戶端程式庫,請參閱 Vision API Product Search 用戶端程式庫。 詳情請參閱 Vision API Product Search Python API 參考說明文件

如要向 Vision API Product Search 進行驗證,請設定應用程式預設憑證。 詳情請參閱「為本機開發環境設定驗證」。

from google.cloud import vision

def get_similar_products_file(
    project_id,
    location,
    product_set_id,
    product_category,
    file_path,
    filter,
    max_results,
):
    """Search similar products to image.
    Args:
        project_id: Id of the project.
        location: A compute region name.
        product_set_id: Id of the product set.
        product_category: Category of the product.
        file_path: Local file path of the image to be searched.
        filter: Condition to be applied on the labels.
                Example for filter: (color = red OR color = blue) AND style = kids
                It will search on all products with the following labels:
                color:red AND style:kids
                color:blue AND style:kids
        max_results: The maximum number of results (matches) to return. If omitted, all results are returned.
    """
    # product_search_client is needed only for its helper methods.
    product_search_client = vision.ProductSearchClient()
    image_annotator_client = vision.ImageAnnotatorClient()

    # Read the image as a stream of bytes.
    with open(file_path, "rb") as image_file:
        content = image_file.read()

    # Create annotate image request along with product search feature.
    image = vision.Image(content=content)

    # product search specific parameters
    product_set_path = product_search_client.product_set_path(
        project=project_id, location=location, product_set=product_set_id
    )
    product_search_params = vision.ProductSearchParams(
        product_set=product_set_path,
        product_categories=[product_category],
        filter=filter,
    )
    image_context = vision.ImageContext(product_search_params=product_search_params)

    # Search products similar to the image.
    response = image_annotator_client.product_search(
        image, image_context=image_context, max_results=max_results
    )

    index_time = response.product_search_results.index_time
    print("Product set index time: ")
    print(index_time)

    results = response.product_search_results.results

    print("Search results:")
    for result in results:
        product = result.product

        print(f"Score(Confidence): {result.score}")
        print(f"Image name: {result.image}")

        print(f"Product name: {product.name}")
        print("Product display name: {}".format(product.display_name))
        print(f"Product description: {product.description}\n")
        print(f"Product labels: {product.product_labels}\n")


其他語言

C#: 請按照用戶端程式庫頁面的 C# 設定說明操作, 然後前往 .NET 適用的 Vision API Product Search 參考說明文件

PHP: 請按照用戶端程式庫頁面上的 PHP 設定說明 操作,然後前往 PHP 適用的 Vision API 產品搜尋參考文件

Ruby: 請按照用戶端程式庫頁面的 Ruby 設定說明操作, 然後前往 Ruby 適用的 Vision API Product Search 參考說明文件

服飾回應範例

Search Image:
  D:/product/final/images-20180618T073733Z-01/images/469355b570ba11e88ff2d20059124800.jpg

圖片搜尋結果

Similar product information:
 Product id: 46930b6b
 Product display name: Evening gown
 Product description: Blue evening gown in 1940s style
 Product category: apparel
 style: women
 category: dress
 color: blue

使用標籤搜尋

以下搜尋範例包含依顏色篩選的條件。

要求

使用方法 get_similar_products_file()get_similar_products_uri() 執行下列要求,發出搜尋要求。產品組合 ID、本機圖片檔案路徑和篩選條件會以引數形式傳遞。輸入圖片也位於「resources/input/」中。

Python

python product_search.py get_similar_products_file "12000002" "D:/product/final/images-20180618T073733Z-001/images/469355b570ba11e88ff2d20059124800.jpg" "color=white"

回應

Search Image:
  D:/product/final/images-20180618T073733Z-001/images/469355b570ba11e88ff2d20059124800.jpg

圖片搜尋結果 2

Similar product information:
 Product id: p569d4e7a1
 Product display name: Wedding Dress
 Product description: Elegant Wedding Dress for women
 Product category: apparel
 style: women
 category: dress
 color: white
